prox.pad Installation/Programming Manual
4.6 Secured Series Front End Program Commands
If you need to change any of the program default values or wish to add functions, first enter program mode and then enter the desired
program command. Defaults are in bold.
Note: The master code must be changed prior to performing any programming on the prox.pad unit.
Table 12: Secured Series Front End Programming Commands
Action Desired Press Details
Enter Program Mode 99 # (Master Code)* Yellow LED blinks slowly
Change master code 1 # (new code) * (repeat code) *
Ex: 1 # 4321 * 4321 *
Code-only operation
Set/clear standard option 30 # option # s/c # ** See Chart below
Option Set Clear
0 – Audio Keypress Feedback 1 = Enabled 0 = Disabled
1 – Visual Keypress Feedback 1 = Enabled 0 = Disabled
2 – Auto Entry 0 = Disabled 1 = Enabled
3 – Operating Mode 0 = Standalone 1 = Front End
14 – Prox Card Anti-Passback Select 0 = Disabled 1 = Enabled
15 – Front End Mode Select 0 = Wiegand Front End 1 = Secured Series Front
End
16 – Secured Series Keypad In/Out Select 0 = In (keypad outside) 1 = Out (keypad inside)
17 – Secured Series Reader In/Out Select 0 = In (reader outside) 1 = Out (reader inside)
20 – Prox Card Type Select 0 = 26 Bit 1 = Corporate 1000
21 – Facility Match Required 0 = Disabled 1 = Enabled
Change Platform Parameters 32 # parameter # value # ** See Chart Below
Parameter Value
2 – 26 Bit Facility Code (for facility code
matching)
0 – 255 (default = 1)
Enter Corporate 1000 Company ID 35 # parameter # value # ** See Chart Below
Parameter Value
0 – Corporate 1000 Company ID 0 – 4095 (default = 4095)
Delete Entire Memory and Reset
System Defaults
46 # 00000 # 00000 # **
To exit Program mode Press * Yellow stops flashing
Document # 6055676, Rev 2.2, D4b Page 79 of 86
