IEI Technology TANK-820-H61 Series User Manual

TANK -820-H61 E mbedded S ystem
Page 4
S pecifications
Memory
1 x 204-pin DDR3 SDRAM SO-DIMM slot (Max. to 10G)
On-board 2GB DDR3 memory
E thernet Controller
Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support
I/O a n d Indicators
E thernet
2 x RJ-45 GbE ports
RS-232
4 x RS-232 serial ports (DB-9)
2 x RS-232 serial ports (DB-9 with isolation)
RS-422/R S -485
2 x RS-422/485 serial ports (RJ-45)
USB Interfaces
4 x USB 2.0 ports on front side
2 x USB 3.0 ports on rear side
Dis play
1 x VGA port (2048 x 1536 @ 75Hz)
1 x DVI-I port (1920 x 1080 @ 60Hz)
Audio Connector
1 x Line-out port
1 x Mic-in port
Digital I/O
1 x DB-9 port on rear side
Interior Expansions
Either one PCIe x8 (via PCIe x16 slot) and two PCI
or one PCIe x1 (via PCIe x4 slot), one PCIe x8 (via PCIe x16 slot)
and one PCI
L E D Indic ators
AT power mode LED
ATX power mode LED
CPU temperature alert LED
HDD LED
Power 1 LED
Power 2 LED
S torage
S ATA
2.5’’ SATA HDD bay
CompactFlash®
One CompactFlash® Type II socket
