5.3.10 F81866 H/W Monitor
The F8186 H/W Monitor menu (BIOS Menu 15) shows the operating temperature, fan
speeds and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
CPU Temperature :+62 C
System Temperature :+37 C
Fan1 Speed :2325 RPM
Fan2 Speed :N/A
Smart Fan Mode Select
---------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 15: Hardware Health Configuration
 P C Health S tatus
The following system parameters and values are shown. The system parameters that are
monitored are:
 System Temperatures:
o CPU Temperature
o System Temperature
 Fan Speeds:
o Fan1 Speed
o Fan2 Speed
5.3.10.1 Smart Fan Mode Configuration
Use the Smart Fan Mode Configuration submenu (BIOS Menu 16) to configure the
smart fan temperature and speed settings.
