TANK -820-H61 E mbedded S ystem
Page 48
7 LPC_AD3 8 LPC_AD2
9 +V3.3S 10 LPC_AD1
11 LPC_AD0 12 GND
13 SMBCLK_MAIN 14 SMBDATA_MAIN
15 +V3.3A 16 INT_SERIRQ
17 GND 18 PM_CLKRUN#
19 PM_SUS_STAT# 20 SIO_DRQ#0
Table 4-12: TPM Connector Pinouts (TPM1)
4.3 E xternal Interface Panel Connectors
The table below shows a list of the external interface panel connectors on the system
motherboard. Pinouts of these connectors can be found in the following sections.
Connector Type Label
Audio jack (mic, line-out) Audio jack JAUDIO1
DIO connector DB-9 DIO1
DVI connector 24-pin female DVI_1
Ethernet and USB2.0 connectors RJ-45, USB 2.0 port USBLAN1,
USBLAN2
Power connector 4-pin DC jack PWR2
Power connector 3-pin terminal block PWR1
RS-232 serial port connectors DB-9 COM1,COM2,
COM3,COM4,
COM7,COM8
RS-422/485 serial port connectors Dual RJ-45 COM5, COM6
USB 3.0 connectors USB 3.0 port USB3_12
VGA connector DB-15 VGA1
Table 4-13: Rear Panel Connectors
