IEI Technology TANK-820-H61 Series User Manual

TANK -820-H61 E mbedded S ystem
Page 66
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Information
Genuine Intel(R) CPU @ 2.40GHz
CPU Signature 306a5
Microcode Patch 7
Max CPU Speed 2400 MHz
Min CPU Speed 1600 MHz
CPU Speed 2400 MHz
Processor Cores 2
Intel HT Technology Supported
Intel VT-x Technology Supported
Intel SMX Technology Not Supported
64-bit Supported
L1 Data Cache 32 kB x 2
L1 Code Cache 32 kB x 2
L2 Cache 256 kB x 2
L3 Cache 3072 kB
----------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: CPU Configuration
The CPU Configuration menu (BIOS Menu 7) lists the following CPU details:
 Processor Type: Lists the brand name of the CPU being used
 CPU Signature: Lists the CPU signature value.
 Microcode Patch: Lists the microcode patch being used.
 Max CPU Speed: Lists the maximum CPU processing speed.
 Min CPU Speed: Lists the minimum CPU processing speed.
 CPU Speed: Lists the CPU processing speed.
 Processor Cores: Lists the number of the processor core
 Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
 Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
 Intel SMX Technology: Indicates if Intel SMX Technology is supported by the
CPU.
 64-bit: Indicates if 64-bit is supported by the CPU.
 L1 Data Cache: Lists the amount of data storage space on the L1 cache.
 L1 Code Cache: Lists the amount of code storage space on the L1 cache.
