TANK -820-H61 E mbedded S ystem
Page 47
4.2.8 S ATA 3 G b/s Drive C onnectors (S ATA1)
PIN NO. DESCRIPTION
PIN
NO.
DESCRIPTION
1 GND 2 SATA20_PTX_C_DRX_P2
3 SATA20_PTX_C_DRX_N2 4 GND
5 SATA20_PRX_C_DTX_N2 6 SATA20_PRX_C_DTX_P2
7 GND 8 GND
9 SATA20_PTX_C_DRX_P3 10 SATA20_PTX_C_DRX_N3
11 GND 12 S ATA20_PRX_C_DTX_N3
13 SATA20_PRX_C_DTX_P3 14 GND
Table 4-9: SATA 3Gb/s Drive Connectors Pinouts (SATA1)
4.2.9 S ATA Power Connector (CN1)
4.2.10 S MB us C onnector (CN3)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 SMBDATA_MAIN
3 SMBCLK_MAIN 4 +V5S
Table 4-11: SMBus Connector Pinouts (CN3)
4.2.11 TPM C onnector (TP M1)
PIN NO. DESCRIPTION
PIN
NO.
DESCRIPTION
1 TPMPCLK 2 GND
3 LPC_FRAME# 4 NC
5 BUF_PLT_RST# 6 +V5S
PIN NO. DESCRIPTION
1 VCC5
2 GND
Table 4-10: SATA Power Connector Pinouts (CN1)
