TANK -820-H61 E mbedded S ystem

Page 51

3 IDATA2_P 4 GND

5 IUSBV2L 6 IDATA3_N

7 IDATA3_P 8 GND

Table 4-18: Ethernet and USB2.0 Connectors Pinouts (USBLAN2)

4.3.6 Power C onnector (PWR2)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 VCC 2 GND

3 VCC 4 GND

5 GND

Table 4-19: Power Connector Pinouts (PWR2)

4.3.7 Power C onnector (PWR1)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 ACCON 2 VCC

3 GND

Table 4-20: Power Connector Pinouts (PWR1)

4.3.8 RS-232 S erial P ort Connector (COM1)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 INDCD1 2 INRX1

3 INTX1 4 INDTR1

5 GND 6 INDSR1

7 INRTS1 8 INCTS1

9 INRI1

Table 4-21: RS-232 Serial Port Connector Pinouts (COM1)

4.3.9 RS-232 S erial P ort Connector (COM2)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 INDCD2 2 INRX2

3 INTX2 4 INDTR2
