IEI Technology TANK-820-H61 Series User Manual

TANK -820-H61 E mbedded S ystem
Page 79
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Smart Fan Mode Configuration
Smart Fan control [Auto PWM Mode]
Temperature of Off 75
Temperature of Start 80
Start PWM 30
Slope(Duty Cycle) [4]
System Smart Fan control [Auto Duty-Cycle Mode]
First Boundary Temperature 60
Second Boundary Temperature 50
Third Boundary Temperature 40
Fourth Boundary Temperature 30
Smart Fan Mode Select
--------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized
Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 16: FAN Configuration
 S mart F an control [Auto PWM Mode]
Use the Smart Fan control BIOS option to configure the CPU Smart Fan.

Full Mode
Fan is on all the time

Manual PWM Mode
The fan spins at the speed set in the manual
setting

Auto PWM Mode DEFAULT
The fan adjusts its speed using these
settings:
Tem perature of Start
Tem perature of Off
Start PWM
Slope (Duty Cycle)
 Temperature of Off [75]
WARNING:
Setting this value too high may cause the fan to speed up only when
