5.3.8.1 S erial P ort n Configuration
Use the Serial Port n Configuration menu (BIOS Menu 12) to configure the serial port n.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
Serial Port n Configuration
Serial Port [Enabled]
Device Settings IO=2C0h; IRQ=11
Change Settings [Auto]
Device Mode [RS232]
Enable or Disable Serial
Port (COM)
---------------------
 : Select Screen
↑ ↓: Select Item
Enter Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 12: Serial Port n Configuration Menu
5.3.8.1.1 S erial Port 7 Configuration
 S erial P ort [E nabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
 Change S ettings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.

IO=2C0h;
IRQ=11
Serial Port I/O port address is 2C0h and the interrupt
address is IRQ11
