TANK -820-H61 E mbedded S ystem
Page 53
4.3.13 RS-232 S erial P ort Connector (COM8)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 -NDCD8 2 NSIN8
3 NSOUT8 4 -NDTR8
5 GND 6 -NDSR8
7 -NRTS8 8 -NCTS8
9 -XRI8
Table 4-26: RS-232 Serial Port Connector Pinouts (COM8)
4.3.14 RS-422/485 S erial P ort Connectors (C OM5)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
A1 N/A A2 ITXD5485#
A3 N/A A4 ITXD5485+
A5 N/A A6 IRXD5485#
A7 N/A A8 IRXD5485+
Table 4-27: RS-422/485 Serial Port Connectors Pinouts (COM5)
4.3.15 RS-422/485 S erial P ort Connectors (COM6)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
B1 N/A B2 ITXD6485#
B3 N/A B4 ITXD6485+
B5 N/A B6 IRXD6485#
B7 N/A B8 IRXD6485+
Table 4-28: RS-422/485 Serial Port Connectors Pinouts (COM6)
4.3.16 USB 3.0 C onnectors (US B 3_12)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 USB3_PWR1 2 USB2P0_DM1_L
3 USB2P0_DP1_L 4 GND
5 USB3P0_RXDN1 6 USB3P0_RXDP1
7 GND 8 USB3P0_TXDN1
