IEI Technology TANK-820-H61 Series User Manual

TANK -820-H61 E mbedded S ystem
Page 77
5.3.9.1.6 S erial Port 6 Configuration
 S erial P ort [E nabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
 Change S ettings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.

IO=2D8h;
IRQ=10
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10

IO=2D0h;
IRQ=10, 11
Serial Port I/O port address is 2D0h and the interrupt
address is IRQ10, 11

IO=2D8h;
IRQ=10, 11
Serial Port I/O port address is 2D8h and the interrupt
address is IRQ10, 11
 Device Mode [RS422/485]
The Device Mode shows Serial Port 6 provides RS-422/485 communications.
