IEI Technology TANK-820-H61 Series User Manual

TANK -820-H61 E mbedded S ystem
Page 73
5.3.9.1.1 S erial Port 1 Configuration
 S erial P ort [E nabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
 Change S ettings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.

Auto DEFAULT
The serial port IO port address and interrupt address
are automatically detected.

IO=3F8h;
IRQ=4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ4

IO=3F8h;
IRQ=3, 4
Serial Port I/O port address is 3F8h and the interrupt
address is IRQ3, 4

IO=2F8h;
IRQ=3, 4
Serial Port I/O port address is 2F8h and the interrupt
address is IRQ3, 4
 Device Mode [RS232]
The Device Mode shows Serial Port 1 provides RS-232 communications.
5.3.9.1.2 S erial Port 2 Configuration
 S erial P ort [E nabled]
Use the Serial Port option to enable or disable the serial port.

Disabled
Disable the serial port

Enabled DEFAULT
Enable the serial port
