2.4 Connectors
The connectors on the WEB-6580 are used to connect external devices
such as hard disk drives, printers, keyboard, CRT, panel, serial ports, etc.
Specifically, WEB-6580 has the following connectors:
CONNECTOR FUNCTION REMARK
J1 VGA Interface DSUB-15
J2 COM1 Serial Interface (RS232) DSUB-9
J3 External Panel Power Connector 5 pin
J4 Reset Button
J5 Power/HDD LED
J6 CD-ROM Audio In Connector 4-pin Mini-Din
J7 Front Panel 8-pin
J8 Panel LVDS Interface
J9 COM2 Serial Port (RS232/422/485) 2x5 pin header
J10 Audio Interface 2x5 pin header
J11 CPLD Program Interface
J12 RTC CMOS Clear
J13 External –12/-5V Interface 4-pin Mini-Din
J14/J15 PC/104 Bus Connector
J16 External USB Interface
J17 External FDD Power Interface
J18 LCD Voltage Select
J19 Standard 5-1/4” Disk Power Connector Big 4 Pin
J20 Compact Flash Card
J22 Panel type select
FDD1 Floppy connector 2x17 pin header
IDE1 IDE1 (Primary) interface
LPT1 Parallel port connector 2x13 pin header
IR1 Standard IrDA (Infrared) port
CN1 Panel TTL interface
LAN1 RJ-45 Ethernet connector
KM1 PS/2 keyboard & mouse connector 6-pin Mini-Din
BT1 Battery socket
