Hardware Configuration Setting
WEB-6580 【 R1.0 】 User’s Manual 2-11
PIN No. Signal Description PIN No. Signal Description
7 Ground 8 USBP1-
9 NC 10 +5V
2-4-16 External FDD Power Connector (J17)
PIN No. Signal Description
1 +5V
2 GND
3 GND
4 +5V
2-4-17 Standard 5-1/4” Disk Power Connector (J19)
PIN No. Signal Description
1 +12V
2 GND
3 GND
4 +5V
2-4-18 Compact Flash Card (J20)
PIN No. Signal Description PIN No. Signal Description
1 Ground 2 D3
3 D4 4 D5
5 D6 6 D7
7 CS#0 8 A10
9 ATA_SEL 10 A9
11 A8 12 A7
13 VCC 14 A6
15 A5 16 A4
17 A3 18 A2
19 A1 20 A0
21 D0 22 D1
23 D2 24 IOCS16
25 CD2 26 CD1
27 D11 28 D12
29 D13 30 D14
31 D15 32 CS1
33 VS1 34 IOR
35 IOW 36 WE#
37 INTRQ 38 VCC
39 CSEL 40 VS2
41 RESET 42 IOCHRDY
43 INPACK 44 REQ
45 DASP 46 PDIAG
