Hardware Configuration Setting
WEB-6580
【
R1.0
】
User’s Manual 2-8
PIN No. Signal Description PIN No. Signal Description
1 +LCD 2 +LCD
3 +LCD 4 +LCD
5 Ground 6 Ground
7 +12V 8 Y0M
9 +12V 10 Y0P
11 Ground 12 Ground
13 +5V 14 Ground
15 +5V 16 Y1M
17 Ground 18 Y1P
19 SKBDATA 20 Ground
21 Ground 22 Ground
23 SMSDATA 24 Y2M
25 Ground 26 Y2P
27 SKBCLK 28 Ground
29 Ground 30 Ground
31 SMSCLK 32 YCM
33 Ground 34 YCP
35 RXD#1 36 Ground
37 Ground 38 VEEON
39 TXD#1 40 Ground
2-4-10 COM2(2x5 Pin header) Interface (J9)
PIN No. Signal Description
1 Data Carrier Detect
2 Received Data
3 Transmit Data
4 Data Terminal Ready
5 Ground
6 Data Set Ready
7 Request To Send
8 Clear To Send
9 Ring Indicator
10 Not used
2-4-11 AUDIO Interface (J10)
PIN No. Signal Description
1 MICPWR
2 N/C
3 LINE_L
4 Ground
5 LINE_R
6 Ground
