System Installation
WEB-6580
【
R1.0
】
User’s Manual 3-3
SXGA+, UXGA and UXGA+ TFT color panels with 9/12/18-bit (both 1
pixel/clock and 2 pixels/clock) and 24-bit interfaces. Enhanced STN hardware with
256 gray scale support and the advanced frame rate control provides 16.7million
color. And the LVDS interface can support another panel. All resolutions are
supported up to 1280x1024.
Supported CRT Screen Resolution is as the following table,
System Memory
Frame Buffer Size Resolution
8MB 16/32MB
640x480x8/16/32
√ √
800x600x8/16/32
√ √
1024x768x8x16x32
√ √
1280x1024x8
√ √
1280x1024x16
√ √
1280x1024x32
√ √
1600x1200x8
√ √
1600x1200x16
√ √
1600x1200x32
√
1920x1440x8
√
1920x1440x16
√
3-3-2 REALTEK 8100BL Network Controller
The REALTEK 8100BL is fully integrated 10BASE-T/100BASE-TX LAN
solution. The 32-bit PCI controller provides enhanced scatter-gather bus mastering
capabilities and enables to perform high-speed data transfers over the PCI bus. Its
bus master capabilities enable the component to process high level commands and
perform multiple operations, which lower CPU utilization by off-loading
communication tasks from the CPU.
The WEB-6580 SERIES provides two LED indicators on RJ-45 connector to
show LAN interface status. These messages will give you a guide for
To Next Page
