BIOS Setup Information
WEB-6580
【
R1.0
】
User’s Manual 4-8
LCD Panel Type 0 0 1 ~ 15
PCI VGA Palette Snoop Disabled Disabled Enabled
Allocate IRQ to PCI VGA Yes Yes No
PCI IDE Bus Master Disabled Disabled Enabled
DMA Channel 0 PnP PnP ISA/ EISA
DMA Channel 1 PnP PnP ISA/ EISA
DMA Channel 3 PnP PnP ISA/ EISA
DMA Channel 5 PnP PnP ISA/ EISA
DMA Channel 6 PnP PnP ISA/ EISA
DMA Channel 7 PnP PnP ISA/ EISA
IRQ3 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ4 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ5 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ7 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ9 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ10 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ11 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ12 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ14 PCI/ PnP PCI/ PnP ISA/ EISA
IRQ15 PCI/ PnP PCI/ PnP ISA/ EISA
▓ PERIPHERAL SETUP DEFAULTS
BIOS Setup Items Optimal Default Failsafe Default Other Options
On Board FDC Auto Auto Enabled, Disabled
On Board Serial Port1 3F8/COM1 3F8/COM1 Disabled 3F8h/COM1,
2F8h/COM2,
3E8h/COM3,
2E8h/COM4,
On Board Serial Port2 2F8/COM2 2F8/COM2 Disabled
3F8h/COM1,
2F8h/COM2,
3E8h/COM3,
2E8h/COM4,
Serial Port2 Mode Normal Normal IrDA, ASK IR
Duplex Mode N/A N/A
On Board Parallel Port 378 378 Disabled, 378, 278,
3BC
Parallel Port Mode Normal Normal Normal, EPP, ECP,
EPP+ECP
EPP Version N/A N/A
Parallel Port DMA Channel N/A N/A
Parallel Port IRQ 7 7 5
On Board IDE Both N/A Auto
Onboard AC’ 97 Audio Enabled Enabled Disabled
▓ HARDWARE MONITOR SETUP DEFAULTS
BIOS Setup Items Optimal Default Failsafe Default Other Options
