Delay for the switching outputs
[dSx] = switch-on delay; [drx] = switch-off delay�
The output does not immediately change its switching status when the
switching condition is met but only after the delay has elapsed� If the switching
condition is no longer met after the delay has elapsed, the switching status of
the output does not change�
[dSx] and [drx] are not effective if [OU1/2] = [OFF]
→ 10.3.6 Set the delay time for switching outputs�
dr1
d52
dr2
t51
Background teach for hysteresis function OUT1
Teach function for [SP1]�
[tS1] is only active if [OU1] = [Hno] or [Hnc]
→ 10.3.2 Set background teach for hysteresis function OUT1 / OUT2�
t52
Background teach for hysteresis function OUT2
Teach function for [SP2]�
[tS2] is only active if [OU2] = [Hno] or [Hnc]
→ 10.3.2 Set background teach for hysteresis function OUT1 / OUT2�
tn1
tf1
Teach switch points for window function OUT1 / 2
Limits at which the output with selected window function changes its switching
status (object present / not present between the distance "near" and the
distance "far")�
[tn1] = switch point "near" / [tF1] = switch point "far"�
[tn1] / [tF1] are only active if [OU1] = [Fno] or [Fnc]�
[tn2] = switch point "near" / [tF2] = switch point "far"�
[tn2] / [tF2] are only active if [OU2] = [Fno] or [Fnc]
(→ 10.3.3 Teach the switch point for window function OUT1 / OUT2)
tb2
td2
Teach switch points for window function OUT2
Teach function for [bP2] / [dP2]�
[tb2] = switch point [bP2] "bright" / [td2] = switch point [dP2] "dark"�
[tb2] / [td2] are only active if [OU2] = [Fno] or [Fnc]�
(→ 10.3.3 Teach the switch point for window function OUT1 / OUT2)
xyl
Set the switching hysteresis levels for OUT2
The switching hysteresis for the object reflectivity can be set in 2 steps: [lo],
[hi] → 10.3.4 Set switching hysteresis level for OUT2
l61
l62
Logic operator of the switching outputs
Status of the switching output 1 / 2 is the result of the logic function of the
following input parameters:
- status of the switching output 1 if no logic function were selected
- status of the switching output 2 if no logic function were selected
→ 10.3.5 Set the logic function for switching outputs�
