10.2.8 Set the switch points for window function OUT1 /OUT2.
► In [OU1], select the output function [Fno] or [Fnc]�
► Confirm with [ENTER]�
► Select [nP1] / [bP2] and set switch point "near" / "bright"�
► Confirm with [ENTER]�
► Select [FP1] / [dP2] and set switch point "far" / "dark"�
► Confirm with [ENTER]�
ou1
np1
fp1
ou2
bp2
dp2
10.3 Extended functions
10.3.1 Set the display
► Change to [EF]�
► Select [diS] and make settings�
2 settings can be selected:
• [On] = the measured value display is activated in the Run mode�
• [OFF] = measured value display is deactivated in the Run mode�
When one button is pressed, the current measured value is displayed
for 15 s�
► Confirm with [ENTER]�
The LEDs remain active even if the display is deactivated�
di5
10.3.2 Set background teach for hysteresis function OUT1 / OUT2
► In [OU1] / [OU2], select the output function [Hno] or [Hnc]�
► Confirm with [ENTER]�
► Change to [EF]�
► Select [tS1] / [tS2]�
> Parameter value for [SP1] / [SP2] is displayed�
► Press the "up" or "down" button and keep it pressed�
> The parameter value flashes for 3 s�
> New parameter value is displayed�
► Confirm with [ENTER]�
> The taught value is saved in [SP1] / [SP2]�
ou1
t51
ou2
t52
