4.2 Output function window
The window function allows monitoring of a defined acceptable range (distance
or reflectivity)� Both outputs (OUT1 and OUT2) can be set as window function →
10�2�8�
Hystereses set automatically by the sensor ensure that the switching
status of the output remains stable at the window limits� Please refer to the
data sheets for the hystereses�
4.3 Switch off the laser
The laser can be switched off via the input on pin 5�
Input signal at pin 5 Laser
Low / not used on
High off
4.4 Logic operator of the switching outputs
The sensor makes it possible to link the switching outputs (distance and
reflectivity) logically�
Three options are available:
Logic Description
OFF no logic block
AND AND operator of OUT1 and OUT2
OR OR operator of OUT1 and OUT2
Thanks to the logic operators, both measurement parameters can be used
for the decision to switch on a switching output� Wiring complexity can be
reduced�
Example:
AND operator on [OUT1] (LG1= AND), [OUT1]= [OUT2]= [hno]�
[OUT1] is switched if
- measured distance value < set switch point [SP1] and
measured reflectivity value > set switch point [SP1]
