16
dfo
Set the fault suppression time for switching outputs
This function suppresses brief saturation of the measuring element (such
saturation may result from direct reflection or strong fluctuations in brightness)�
During the set delay time, the latest valid value measured is displayed, the
output signals remain unchanged�
(→ 10.3.7 Set the fault suppression time)�
di5
Set the display
2 settings can be selected:
[on], [OFF]
With the setting [OFF], the display is switched off automatically after 30 sec�
Only the "power-on" LED remains active�
Each push of the button re-activates the display for 15 sec�
(→ 10.3.1 Set the display)
9 Operating modes
9.1 Run mode
The run mode is the normal operating mode�
After power on the unit is in the Run mode� It carries out its monitoring function
and generates output signals according to the set parameters�
The display indicates the current distance or the object reflectivity, the yellow
LEDs signal the switching status of the outputs�
The measuring distance is displayed in [cm]�
• Value range 0���99�9 cm with one decimal place (mm resolution)
• Value range 100���165 cm without decimal place (cm resolution)
The object reflectivity is displayed in [%]:
• Value range = 0���999
- A value of 100% corresponds to the reflectivity of a white Kodak Gray
Card if the sensor is aligned vertically to the object�
- A value of 20% corresponds to the reflectivity of a grey Kodak Gray
Card if the sensor is aligned vertically to the object�
Reflective surfaces can generate values considerably larger than 100%�
Switch between the two measured values via the "up" or "down" button�
