13 Maintenance, repair, disposal
Faulty sensors must only be repaired by the manufacturer�
► Keep the front lens of the sensor clean�
► After use dispose of the unit in an environmentally friendly way in accordance
with the applicable national regulations�
► Do not open the module housing� There are no user-serviceable components
inside�
14 Scale drawing
Original Scale Drawing (MTD)
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 31,5 mm
P_MZ_200_0404
30% 333,4%
24,1
45,2
14,2
4,2
14,2
3,3
LEDs
M18x1
22,5
M12x1
61,7
1
2
24,1
45,2
14,2
4,2
14,2
3,3
LEDs
M18x 1
22,5
M12x 1
61,7
1
2
Dimensions in mm
1: 3-digit alphanumeric display / LED function displays
2: Programming buttons
