IFM OGD582 - Error Indications for Output 1; Error Displays for Output 2

29
UK
12.1 Error indications
12.1.1 Error indications for OUT1
Display Possible cause Switching output
[Hno] [Hnc] [Fno] [Fnc]
[ - |- ]
too much light,
e�g� reflective surface
ON OFF OFF ON
[--]
not enough light, no object
OFF ON OFF ON
[nEA]
object to be measured
outside the measuring range
< 80 mm
ON OFF OFF ON
[FAr]
object to be measured
outside the measuring range
> 165 cm
OFF ON OFF ON
[OFF]
laser is switched off
OFF ON OFF ON
[ERP]
plausibility
(e�g� object too fast)
X
1)
X
1)
X
1)
X
1)
[ute]
ambient temperature too
low, laser is switched off
OFF ON OFF ON
[SC1] short circuit in switching output 1
12.1.2 Error displays for OUT2
Display Possible cause Switching output
[Hno] [Hnc] [Fno] [Fnc]
[ - |- ]
too much light,
e�g� reflective surface
ON OFF OFF ON
[--]
not enough light, no object
OFF ON OFF ON
[nEA]
object to be measured
outside the measuring range
< 80 mm
X
1)
X
1)
X
1)
X
1)
[FAr]
object to be measured
outside the measuring range
> 165 cm
X
1)
X
1)
X
1)
X
1)
[OFF]
Laser is switched off
OFF ON OFF ON
[ERP]
plausibility
(e�g� object too fast)
X
1)
X
1)
X
1)
X
1)
[ute]
ambient temperature too
low, laser is switched off
OFF ON OFF ON
[SC2] short circuit in switching output 2
1)
unchanged
