P22
Min/Max
Allows you to dene the minimum and/or maximum
dimming levels. Both settings are expressed as per-
centages of the total standard dimming range. When
the range of an Output is congured in this way, its
reduced dimming range will be scaled to t within the
normal 0 to 100% dimming instructions received from
wallstations and other controllers. This option is only
applicable to the loads connected to the optional HF
card accessory.
Operation at Min
For a 0-10V load connected to the optional HF card
accessory. This option determines what the Output
should do when the chosen Minimum level is reached.
When this option is set to ‘Turn Off’, the Output will
switch off when the corresponding minimum level
is reached.
When this option is set to ‘Stay at Min’, the Output will
remain at the corresponding minimum level.
Startup Action
This option determines how the selected Output
should recover from a power failure once the supply is
restored. There are three settings available:
• Restore Last Scene reinstates the scene that was
being displayed when the power outage occurred.
• Use Emergency Scene will display the scene that
is dened within the ‘Conguration’ > ‘Emergency
Scene Edit’ option.
• Select Scene allows you to assign any standard
scene numbered up to 128. When you select this
setting, a sub page will request the scene number.
To Next Page
