A20733 B0 107
ADJUSTMENT AND REPLACEMENT
PROCEDURES 2
Contents
1 Adjustment procedures 108
1.1 Jet break-off point 108
1.2 Adjusting the jet in the gutter 110
1.3 Adjusting the pressure motor speed 114
2 Replacement procedures 115
2.1 Replacing the mains fuse (4 A delayed-action fuse) 115
2.2 Changing the ink 116
2.3 Replacing the ink filter cartridge 117
2.4 Replacing the pressurization air filter 118
