Imaje S8 Classic - 1.3 Print Head

6 A20733 B0
Presentation
1.3 Print head
Figure 1: Overall view of print head with cover open
1 Gutter open/close tap
2 Recuperation gutter
3 Deflection plates
4 Detection electrode
5 Charge electrode
6 Cannon
7 Nozzle rinse spray
Figure 1
fig 20
6
5
4
3
2
1
7
