A20733 B0 135
Input / Output Connections
3 Outputs
3.1 "General alarm" output
•Role:
This output signals a printer malfunction which does not stop printing. This alarm is generated to
warn the operator to correct the cause of the anomaly.
Two types of contact are available for this output: an "Inactive" (normally closed) dry contact or
an "Active" (normally open) dry contact.
3.2 "Jet alarm" output
•Role:
This output signals a printer malfunction which stops printing.
This output may be connected to a girolamp or a siren, and also to the conveyor control system to
stop the production line.
When the fault output is activated, the alarm output is always activated at the same time.
Two types of contact are available for this output: an "Inactive" (normally closed) dry contact or
an "Active" (normally open) dry contact.
3.3 Electrical characteristics of the outputs
• Max. voltage: 250 Vac
• Max. current: 1 A
For a DC voltage, the maximum permitted current is 1 A.
These are potential-free dry contacts, which can be used to control alarm systems or electrical
assemblies directly connected to the mains.
The electrical contacts are protected by RC filters (0.1 µF/250 V + 47 Ω).
Whatever the type of voltage (AC or DC) applied to these terminals, the filter should never be
disconnected.
