98 A20733 B0
Troubleshooting
2.2 Appearance of the electronic compartment and industrial interface board
The location of the boards are shown in figures 1 and 2.
Figure 1: Console electronics compartment
1 Motor control board *
2 Power supply board
3 Main board
4 Front panel board
* The motor control board is Installed on main board connectors J13
and J21 on S8 Egg Classic printers.
Figure 2:Industrial interface board compartment
1 Industrial interface board
2 3-pin socket with fuse
Figure 1 Figure 2
2
1
4
1
2
3
