A20733 B0 97
Troubleshooting
2.1.2 Ink circuit: S8 Egg Classic
Front view Rear view
1 Ink tank
2 Additive tank
3 Condenser with fan
4 Viscometer drain electrovalve
Additive addition electrovalve
5 Nozzle rinsing electrovalves
6 Anti-pulse
7 Ink filter
8 Pressure / temperature sensor
9 Pressure pump / by-pass adjustment
10 Viscometer
11 Motor and vacuum pump for head 1
3
1
2
4
5
6+7+8
9
10
11
