24 A20733 B0
NOTE To temporarily delete an option, alter the corresponding bit
from 1 to 0.
IMPORTANT The value 0 is saved. To recover the initial option,
set the corresponding bit to 1.
Choices
The CPU options are indicated by two sets of 8 digits (bits).
Each bit corresponds to one option and can be either "0" or "1".
The option is present in the printer if the corresponding bit is set to "1".
10000000 10000000
Ink type
Operation "spy"
Autodating stop
Reserved distribution bar code
Reserved
Reserved
0 = "Counter" mode 1 = "Stop message" mode
1 = Object counter 0 = Message counter
Reserved
Reserved
1 = Industrial bar code 0 = No bar code
0 = Double line 1 = No double line
1 = Message library 0 = No library
1 = Nozzle rinsing 0 = No rinsing
(position
the cursor on
the desired bit)
b , d , 0
CPU and print boards
