Servicing
DRAINING
After connecting the draining tool, this function can be used to monitor the operation of the
automatic draining cycle
IMAJE SAV
This function displays a recorded history of the printer’s operating parameters.
Records are at five-minute intervals, and several hours of operation are stored.
The following parameters are stored
-Time
- Vmot: Motor speed (rpm)
- Pres: Ink pressure (bar)
- Tr: Viscometer filling time (s)
- Ad: Number of additive additions
- Vjet: Jet speed (m/s)
- T1: Electronic circuit temperature (°C)
- T2: Ink circuit temperature (°C)
- Def: Hexadecimal value of "general faults" byte.
The two lines below are displayed alternately:
The first record displayed corresponds to the most recent machine status.
g Displays previous records.
d Displays subsequent records.
Contents of "General fault" byte:
Bit 7 Ink pigment circuit Bit 3 Memory lost
Bit 6 Motor cycle Bit 2 Hard CPU
Bit 5 Head 2 unserviceable Bit 1 Pressure
Bit 4 Head 1 unserviceable Bit 0 Ink level low
E12
E13
12:3115002.76290120.1352100
Time Vmot Pres Tr Ad Vjet T1 T2 Def
To Next Page
