10/53 IMET - M550 ALL1-EN
Prima di eseguire qualsiasi tipo di lavoro, togliere
la tensione e leggere il manuale di istruzione.
Avant d'effectuer n'importe quel type de travail,
couper la courant et lire le notice pour l'usager.
Before carrying-out any type of work, turn-off
the voltage and read the user's manual.
Bevor irgendwelche Arbeit ausgefuehrt wird,
Spannung unterbrechen und
Bedienungsanleitungen lesen.
Working
RF Busy Power Supply
Imax=0.9A 20VA
50/60Hz
IP65
M550S - UHF ISM Band
Data Error ch. A Data Error ch. B
Supply
Power
Serial no.
24/48-55/110/230V
Radio Model
Class Protection
RX Unit Mod. M550S LAC
Passive Emergency ch. B Passive Emergency ch. A
162
153
64
The dimensions correspond to 14 mod. DIN.
182
120
ACK
RTS
STROBE
RXD
ERROR
TXD
747372717069686766656463626160595857565554535251
AD OUT 8 AD OUT 7 AD OUT 6 AD OUT 5 GND OUT VREF D0 D1 D2 D3 D4 D5 D6 D7 +VIN GND AIN1 AIN2 AIN3 AIN4 +5V
LB534
ANT
LB304
LB306
DATA ERROR CH. A EMERGENCY CH. A POWER SUPPLY EMERGENCY CH. B DATA ERROR CH. B WORKING
B1 B2 B3 B4 B5 B6 B7 B8 A1 A2 A3 A4 A5 A6 A7 A8
C1 C2 C3 C4 C5 RF BUSY
LB422
75 76
77
78 79
LN
13 - 24V
T 1.25A L250V
T 5A L250VT 5A L250V
LB309
13 - 24VSupply DC
Radio Model M550D - UHF ISM Band
TRX Unit Mod. M550D MAC
Serial no.
Power
Supply AC 13 - 24V 50/60Hz
1,2A 20VA
LB305
0470
L and K versions
