IMET M550 - Operation

36/53 IMET - M550 ALL1-EN
MAX RANGE
It is possible to connect multiple iREaDy in parallel according to the diagram shown here below
7.3.4. Operation
Once the initial conditions from the user manual have been verified (Chap. 6.2), proceed as
follows:
• For one second, activate the START control pointing the front part of the pushbutton
towards the infrared receiver with an angle of inclination and a distance that conforms to
what is contained in paragraph 7.3.5.
• When the green LED switches on it indicates that the transmitter is functioning correctly.
• A temporary switch on of the green LED (DATA) on the infrared receiver indicates that
the two units are aligned correctly.
• When the white LED (START) of the infrared receiver switches on, it indicates that the
START command of the radio remote control has been activated. From this moment on,
it is possible to carry out the commands.
Range of action of the infrared receiver
RX
iREaDy
relay
START
ralay
START
1
iREaDy
relay
2
iREaDy
relay
n
...
COMANDO
P
9
P
2
P
1
T
E
S
E
R
S
E
R
T
E
R E
S
E
T
P O
T
S
T
S
O
P
P
9
P
2
P
4
P
6
P
1
P
3
P
5
T
E
S
E
R
S E
R
T
E
R
E
S
E
T
P
O
T
S
T
S
O
P
P
8
P
7
