10.5. H receivers
• Type of RF receiver Superheterodyne IF 83.16 MHz - 455 kHz
• RF emission power* 10 mW ERP (internal antenna)
• Emission class* 25K0F1D
• Oscillator type* Synthesizer
• Power supply voltage 24, 48, 55, 110 and 230 V AC, 12÷28 V DC
• Absorbed power 20W Max
Maximum absorption ≅ 0,9 A in AC / 1,2 A in DC
• Max. number of control relays (NC/NO) 48
• Number of service relays (NO) 4
• Max. number of analogue commands 8
TYPE OF OUTPUT TYPE OF
COMMAND
OUTPUTS AC POWER DATA DC POWER DATA
E-STOP relay
Relay 1 NO 6A/130-250V AC1 6A/28V DC1
Safety-Stop relay
Relay 1 NO 6A/130-250V AC1 6A/28V DC1
Service relay
Relay 4 NO/NC 12A /130-250V AC1 12A/28V DC1
RST relay card
Relay 3 NO+
12 NO/NC
12A /130-250V AC1
RSA relay card
Relay 3 NO+
12 NO/NC
12A/28V DC1
RMP relay card
Relay 10 12A /130-250V AC1
RMA relay card
Relay 10 12A/28V DC1
PWM DAC+C1
current-operated
analog card
Proportional
analog
8
0 ÷ 1.4 A
(F= 40÷150 Hz;
F=200 ÷600 Hz)
DAC+C2 current-
operated analog
card
Proportional
analog
8
0 ÷ 20 mA
4 ÷ 20 mA
DAC+V voltage-
operated analog
card
Proportional
analog
8
25% ÷ 50% ÷75%V DC
0V DC ÷ (V DC-3) V
DCmax=28V DC
-10V DC ÷ 0V DC ÷ 10V
DC
• Input port* Serial/Parallel
• Max. number of digital inputs* 8
• Max. number of analogue inputs 4
• Parallel port data exchange speed* 50000 char/s
• Asynchronous serial port data exchange speed* 4800/9600 bit/s
• * Transceiver version
