10.7. K receiver
Type of RF receiver Superheterodyne IF 83.16 MHz - 455 kHz
RF emission power* 10 mW ERP (internal antenna)
Emission class 25K0F1D
Oscillator type* Synthesizer
Power supply voltage 12 - 28 V DC
Absorbed power 15W Max
Maximum absorption 1,2 A in DC
Max. number of control relays 16
Max. number of control relays (NC/NO) 4 (only with RDC relay cards)
Max. number of service relays (NO) 3 (between START, HORN, LAMP and T-STOP)
Max. number of DC command drivers 20
Max. number of analog outputs 8
TYPE OF OUTPUT TYPE OF
COMMAND
OUTPUTS AC POWER DATA DC POWER DATA
E-STOP relay
Relay 1 NO 6A/28V DC1
Safety-Stop relay
Relay 1 NO 6A/28V DC1
Service relay
Relay NO/NC 3 NO 12A/28V DC1
RDC relay card
Relay 12 NO+
4 NO/NC
12A/28V DC1
RMC relay card
Relay 14 NO 16A/28V DC1
RLS driver card
MOSFET 20 6A/28V (L=0)
2A/28V (L=10mH)
PWM ADD+C1
current-operated
analog card
Proportional
analog
8
0 ÷ 1.4 A
(F= 40-150 Hz;
F=200 ÷ 600 Hz)
ADD+C2 current-
operated analog
card
Proportional
analog
8
0 ÷ 20 mA
4 -÷ 20 mA
ADD+V1 voltage-
operated analog
card
Proportional
analog
8
25% ÷ 50% ÷ 75%V DC
0V DC ÷ (V DC-3) V
DCmax=28V DC
-10V DC ÷ 0V DC. ÷
10V DC
• Input ports* CAN/Serial/Parallel
• Max. number of digital inputs* 8
• Max. number of analog inputs* 4
• CAN bus interface data exchange speed* <= 500 kbit/s
* Transceiver version
