IMET - M550 ALL1-EN 33/53
MtrS MtrS Easy
• Keep the Lock button pressed (see technical
attachments).
• Press the start button for 1 s.
• Once the Start button is released, verify that all selected
receivers activate the lit signal of the transmitter with
which it intends to operate.
• Release the lock button.
Procedure unnecessary.
Once Start is pressed, all selected
receivers will start (see paragraph
2.4)
From this moment the receivers are for the exclusive use of the transmitter. No other transmitters will
be able to control the selected receivers until the Unlock procedure is carried out
7.1.1.4. Radio remote control start-up
Once the initial conditions of the user manual are verified (Chap. 6.2), press the START button to
operate. All selected receivers with the Lock procedure will activate and from this moment it will be
possible to carry out the desired manoeuvres.
During the work session it is possible to switch from one combination to another. Before this
operation, always interrupt the gear by pressing STOP. If not, the transmitter will automatically switch
itself off.
If the receivers are already being exclusively used: choose the new desired combination with the
rotating selector and press start.
If the receivers are not being used exclusively: choose the new desired combination with the
rotating selector and repeat the desired Lock procedure. Then press START.
7.1.1.5. UNLOCK Procedure
Once the working session is finished, to once again be able to make the receivers available to other
operators, it is necessary to free the receivers from the exclusive use of the transmitter.
MtrS MtrS Easy
• Radio remote control not started
• Choose a combination of receivers to be freed by way of
the toggle switch (if the toggle switch is not present,
pass on to the next point).
• Keep the Unlock control pressed (see technical
attachments).
• Press the start key for 1 s.
• Radio remote control started
• Press the UNLOCK button for 1 s
at the first click (see technical
attachments)
Verify that all selected receivers deactivate the lit signal indicated the transmitter which had the
exclusive control.
From this moment the receivers are free and can operate with the other transmitters which form part
of the system.
7.1.1.6. Frequency change
The frequency change is carried out in the same mode described in chap 8 of the main manual.
The initial condition to be respected is that the transmitter must not
have any selected receiver
at exclusive use.
Attention: with the MtrS or MtrS Easy option, the receiver does not give any information that
the frequency change has been carried out. Keep to the information of the LED of the
transmitting unit
7.1.2. Receiver
Inside the receiver with the MtrS and MtrS Easy option there are outputs destined to the signalling the
transmitter which, at that time, has exclusive use of the receiver. For safety, every machine will have
to be equipped with lit signals which inform various operators which transmitter has the exclusive use
of the receiver at that time.
The number of dedicated outputs are:
• From 1 to 4 for L and M receivers.
