42/53 IMET - M550 ALL1-EN
10. TECHNICAL SPECIFICATIONS
• Manufacturer IMET S.r.l.
• Operating frequency I.S.M. Band 434.050 ÷ 434.775 MHz
• Modulation GMSK Dev. 3 kHz
• Receiver sensitivity 0.22 uV 12 dB Sinad
• F. offset block or desensitisation +/- ( 50-1000 KHz) -40 dBm
• F. offset block or desensitisation +/- (2 MHz) -25 dBm (Limit >= -69 dBm clause 9.4
ETSI EN 300-220-1)
• F. offset block or desensitisation +/- (10 MHz) -10 dBm (Limit >= -44 dBm clause 9.4
ETSI EN 300-220-1)
• Channelling 25 KHz Simplex, (25 KHz Half Duplex)*
• Emission designation 25K0F1D
• Number of programmable channels 30
• Range ≅ 100 m
• Hamming distance ≥ 9
• Error non-detection probability < 7.34x10
-12
• Available pairing addresses 65536
• Delay time at receiver start-up < 3 s
• Delay time at start command < 750 ms
• Command response time < 110 ms, (< 120 ms)*
• STOP circuit response time < 150 ms, (< 220 ms)*
• Passive emergency operate time < 500 ms (1200ms optional)
• STOP circuit safety class 4
(UNI EN 954-1) PL e ( ISO 13849-1)
Movement commands safety class 2 ÷ 3
(UNI EN 954-1)
PL c ÷ PL d
( ISO 13849-1) (see Annex B)
Feedback controls safety class 1*(UNI EN 954-1)
PL c
( ISO 13849-1)
• Number of safety controls 2 (Safety-Stop, STOP)
• Operating and storing temperature range -20°C ÷ +70°C (-4°F ÷ +158 °F)
• Casing protection degree IP 65 (except for versions M and M8)
• Portable units housing material Glass-filled nylon
• Housing material of versions M-AC and M8 (DIN) PVC
• Fixed units housing material ISONYL V0
WAVE transmitters with H, L and K receivers
• Max. number of ON/OFF commands 16 (WAVE S), 20 (WAVE L)*, 24 (WAVE L)
• Number of service commands 1 Horn
• Max. number of analog commands 1
• Max. number of switch commands (optional) 4
* Transceiver version
WAVE transmitters with M receivers
• Max. number of ON/OFF commands 16 (WAVE S), 20 (WAVE L)*, 21 (WAVE L)
• Number of service commands 1 Horn
• Max. number of analog commands 1
• Max. number of switch commands (optional) 4
* Transceiver version
THOR, ZEUS, S1, S2, G4, M8 transmitters with H receivers
• Max. number of ON/OFF commands 48, 38*
• Number of service commands 4 (Start, Horn, Lamp, T-Stop)
• Max. number of analog commands 8 (with 38 ON/OFF commands)
* Transceiver version
THOR, ZEUS, S1, S2, G4, M8 transmitters with L and K receivers
• Max. number of ON/OFF commands 20
• Number of service commands 1 ÷ 3 (Start; Horn and T-Stop optional)
• Max. number of analog commands 8
