IMET M550 - System Identification Codes

IMET - M550 ALL1-EN 5/53
1. Identification data
RECEIVING UNIT ID
M550
H
Cable clamp output
I
Recessed multipolar plug
output
L
Cable + plug output
M
ACK RTS
STROBE
RXD
ERROR
TXD
747372717069686766656463626160595857565554535251
AD OUT 8 AD OUT 7 AD OUT 6 AD OUT 5 GND OUT VREF D0 D1 D2 D3 D4 D5 D6 D7 +VIN GND AIN1 AIN2 AIN3 AIN4 +5V
LB534
ANT
LB304
LB306
DATA ERROR CH. A EMERGENCY CH. A POWER SUPPLY EMERGENCY CH. B DATA ERROR CH. B WORKING
B1 B2 B3 B4 B5 B6 B7 B8 A1 A2 A3 A4 A5 A6 A7 A8
C1 C2 C3 C4 C5 RF BUSY
LB422
75 76 77 78 79
LN
13 - 24V
T 1.25A L250V
T 5A L250VT 5A L250V
LB309
13 - 24VSupply DC
Radio Model M550D - UHF ISM Band
TRX Unit Mod. M550D MAC
Serial no.
Power
Supply AC 13 - 24V 50/60Hz
1,2A 20VA
LB305
0470
Unwired output
Single transmission
S
Dual transmission
D
Integrated circuit
board
L
Modular circuit board
H
DIN rail
M
BUS receiver
K
Version
External antenna
O
L and K
H
M
Internal antenna
I
L and K
H
Whip antenna
S
L-AC only
Project reference number
nnnn
Alternating current power supply
AC
Direct current power supply
DC
A
24V AC power supply
B
48V AC power supply
C
55V AC power supply
D
110V AC power supply
E
230V AC power supply
F
Power supply selectable from A to E
G
18-28V AC power supply
N
12-28V DC/AC power supply
