IMET - M550 ALL1-EN 43/53
THOR, ZEUS, S1, S2, G4, M8 transmitters with M-AC receivers
• Max. number of ON/OFF commands 21
• Number of service commands 3 (Start, Horn and Blinker)
• Max. number of analog commands 4
10.1. WAVE transmitter
• RF emission power 10 mW ERP (internal antenna)
• Emission class 25K0F1D
• Oscillator type Synthesizer
• Power supply voltage 2.4 V DC
• Absorbed current 100 mA, 120mA*
• Max. absorbed power 0.3 W*
• IMET battery Ni-MH 2.4V 1.5 A/h
• Run time at 20 °C with charged battery, continuous operation ≅ 15 hours, 12 hours*
• Low battery warning time ≅15 min
• Liquid Crystal Display * 2 lines, 8 characters/line (30x15 mm)
• Visualization speed of characters on display* 100 char/s
10.2. THOR and ZEUS transmitters
• RF emission power 10 mW ERP (internal antenna)
• Emission class 25K0F1D
• Oscillator type Synthesizer
• Power supply voltage 3.6 V DC
• Absorbed current 160 mA, 180 mA*
• Absorbed power 0.58 W, 0.65 W*
• IMET battery Ni-MH 3.6V 1.7 A/h
• Run time at 20 °C with charged battery, continuous operation ≅ 11 hours, 9 hours*
• Low battery warning time ≅15 min
• Liquid Crystal Display* (Optional) 4 lines, 20 characters/line (75x27 mm)
• Liquid Crystal Display* (Standard) 2 lines, 16 characters/line (55x15 mm)
• Visualization speed of characters on display* 100 char/s
10.3. S1, S2 and G4 transmitters
• RF emission power 10 mW ERP (internal antenna)
• Emission class 25K0F1D
• Oscillator type Synthesizer
• Power supply voltage 6 V DC
• Absorbed current 90 mA, 110mA*
• Absorbed power 0.54 W, 0.66 W*
• IMET battery Ni-MH 6V 1 A/h
• Run time at 20°C with charged battery, continuous operation ≅ 11 hours, 9 hours*
• Low battery warning time ≅15 min
• Liquid Crystal Display* 2 lines, 16 characters/line (55x15 mm)
• Visualization speed of characters on display* 100 char/s
10.4. M8 transmitter
• RF emission power 10 mW ERP (external antenna)
• Emission class 25K0F1D
• Oscillator type Synthesizer
• Power supply voltage 12V÷28V AC/DC
• Absorbed current 240 mA, 260 mA*
• Absorbed power 1.40 W, 1.50 W*
• Liquid Crystal Display* (Optional) 4 lines, 20 characters/line (75x27 mm)
• Liquid Crystal Display* (Standard) 2 lines, 16 characters/line (55x15 mm)
• Visualization speed of characters on display* 100 char/s
• Max. number of ON/OFF outputs (NO relay)* 16
• Relay max. capacity* 6A 130V - AC1 / 6A 28V -DC1
• Input ports 21 digital, 8 analog
* Transceiver version
