10.8. M-AC receivers
Type of RF receiver Superheterodyne IF 83.16 MHz - 455 kHz
RF emission power* 10 mW ERP (external antenna)
Emission class* 25K0F1D
Oscillator type* Synthesizer
Power supply voltage 12 ÷ 28 V AC / 12 ÷ 28 V DC
Absorbed power 20W Max
Maximum absorption 1,2 A in DC
Max. number of control relays 17
Max. number of control relays (NC/NO) 4
Max. number of service relays (NO) 3 (START, HORN, LAMP)
Max. number of analog outputs 8
TYPE OF OUTPUT TYPE OF
COMMAND
OUTPUTS AC POWER DATA DC POWER DATA
E-STOP relay
Relay 1 NO 6A/130V AC1 6A/28V DC1
Safety-Stop relay
Relay 1 NO 6A/130V AC1 6A/28V DC1
Service relay
Relay 3 NO 6A/130V AC1 6A/28V DC1
Control relay
Relay 17 NO
4 NO/NC
6A/130V AC1 6A/28V DC1
ADD+V1 voltage-
operated analog
card
Proportional
analog
4
25% ÷ 50% ÷ 75%V DC
0V DC ÷ (V DC-3) V
DCmax=28V DC
-10V DC ÷ 0V DC ÷ 10V
DC
ADD+C2 current-
operated analog
card
Proportional
analog
4
0 ÷ 20 mA
4 ÷ 20 mA
Data acquisition input ports* RS232/RS485/Parallel
Max. number of digital inputs* 8
Max. number of analog inputs* 4
Parallel port data exchange speed* 50000 char/s
Asynchronous serial port data exchange speed* 4800/9600 bit/s
* Transceiver version
