TECHNICAL DATA
4
TECHNICAL DATA
4.1 VARIABLE HEAT OUTPUT
e power data in the table has been obtained with intake-exhaust pipe measuring 0.5 m in length. Gas ow rates refer to net
caloric value below a temperature of 15°C and at a pressure of 1013 mbar.
Victrix Tera V2 24 Plus EU
METHANE
(G20)
PROPANE
(G31)
FLOW RATE
OUTPUT
HEAT
OUTPUT
FAN R EVS
MODULA-
TION
GAS FLOW RATE
BURNER
FAN R EVS
MODULA-
TION
GAS FLOW RATE
BURNER
(kW) (kW) (rpm) (%) (m
3
/h) (rpm) (%) (kg/h)
28,7 28,0 D.H.W. 5900 100 3,04 5900 100 2,23
24,5 24,0
HEAT. +
D.H.W.
5100 83 2,59 5100 83 1,90
23,5 23,0 4925 79 2,49 4925 79 1,83
22,0 21,5 4625 73 2,33 4625 73 1,71
21,0 20,5 4450 69 2,22 4450 69 1,63
19,5 19,0 4175 63 2,06 4175 63 1,51
18,5 18,1 3975 58 1,96 3975 58 1,44
17,0 16,6 3700 52 1,80 3700 52 1,32
16,0 15,6 3500 48 1,69 3500 48 1,24
14,5 14,1 3225 42 1,53 3225 42 1,13
13,5 13,2 3050 38 1,43 3050 38 1,05
12,0 11,7 2750 31 1,27 2750 31 0,93
11,0 10,7 2575 27 1,16 2575 27 0,85
9,5 9,2 2300 21 1,01 2300 21 0,74
8,5 8,2 2100 17 0,90 2100 17 0,66
7,0 6,8 1825 11 0,74 1825 11 0,54
6,0 5,8 1625 6 0,63 1625 6 0,47
4,5 4,3 1350 0 0,48 1350 0 0,35
