1.15 MAXIMUM FLUE LENGTH
Type Installation VICTRIX TERA V2 24 PLUS EU
L = Maximum length (m)
Ø 60/10 0mm
C13 (horizontal+curve) 13
C33 (vertical) 14,5
Ø 80/125mm
C13 (horizontal+elbow) C33 (vertical) 35
C(10)3 - C(12)3 10
Ø 80/80mm
C43 - C53 - C83 (split) 35
C(10)3 - C(12)3 15
B23 - B23p - B33 - B53 - B53p 30
Ø 50 exible
C53 Split duct 80/80 from boiler to connection in ue
20
Ø 60mm rigid 25
Ø 80mm rigid 35
Ø 80 exible 30
Ø 50 exible
C93 Concentric 60/100 or 80/125 from boiler to ue
20
Ø 60mm rigid 25
Ø 80mm rigid 35
Ø 80 exible 30
Note: Installation C10-C12 type-approved only with G20 gas.
Type Installation VICTRIX TERA V2 35 PLUS EU
L = Maximum length (m)
Ø 60/10 0mm
C13 (horizontal+curve) 13
C33 (vertical) 14,5
Ø 80/125mm
C13 (horizontal+elbow) C33 (vertical) 35
C(10)3 - C(12)3 10
Ø 80/80mm
C43 - C53 - C83 (split) 35
C(10)3 - C(12)3 15
B23 - B23p - B33 - B53 - B53p 30
Ø 50 exible
C53 Split duct 80/80 from boiler to connection in ue
13
Ø 60mm rigid 25
Ø 80mm rigid 35
Ø 80 exible 30
Ø 50 exible
C93 Concentric 60/100 or 80/125 from boiler to ue
13
Ø 60mm rigid 25
Ø 80mm rigid 35
Ø 80 exible 30
Note: Installation C10-C12 type-approved only with G20 gas.
e values indicated in the table are the maximum available lengths.
Adjustment of the maximum boiler speed depending on the length of the actual pipes installed must refer to the Table in Par.
3.8.
e ue parameter (heat output) must be calibrated by the maintenance technician at initial testing.
