TYPE OF DUCT
Equivalent
length in m
of concentric pipe
exible Ø 80
Bend support Ø 80 mm M/F at 87°
m 0,5
Flexible adapter M Ø 80
m 0,15
Support bend Ø 80 mm at 70°
m 1
Ø 80 mm exible hose (1 m)
m 1
Vertical terminal Ø 80/125 mm (C
5
- C
9
) m 0,7
Female exible adapter Ø 80
m 0,2
Flexible adapter/hose Ø 80
m 0,3
