TYPE OF DUCT
Equivalent
length in m
of concentric pipe
exible Ø 50
Bend support Ø 80 mm M/F at 87°
m 0,6
Ø 50 mm exible hose (1 m)
m 1
Vertical terminal Ø 80/125 mm (C
5
- C
9
) m 0,5
Terminal with 90° bend (C
5
) m 1,2
"T-shaped" terminal Ø 80 (C
5
) m 1
Flexible/rigid adapter (female/female)
m 0,35
