INSTALLERUSERMAINTENANCE TECHNICIANTECHNICAL DATA
1.5 INSTALLATION INSIDE THE RECESSED FRAME OPTIONAL
e appliance is designed for installation inside the Immergas recessed frame (supplied as optional).
e necessary parts for this type of installation (brackets) must also be purchased separately as optional kit.
To install proceed as follows:
- Install the bracket (2) inside the recessed frame xing it with the screws (3) in the pre-drilled holes (Fig. 4).
- Hang the boiler (4) to the bracket (2) (Fig. 5).
- Block the boiler (4) by mounting the brackets (5) and xing them with their screws (6) (Fig.6).
e brackets (5) used to centre the appliance on the frame and hold it in place stop against the frame (1) so do not require xing to the
frame itself.
1
2
3
3
4
1
4
2
2
5
1
4
5
6
5
6
6
