1.24 CONFIGURATION C
10
 C
12
SEPARATOR KIT Ø 80/80
In the C
(10)
and C
(12)
installations, the appliance ue exhaust must be tted with a ue gas
non-return valve kit, supplied by Immergas as an optional, consisting of the valve itself with
instructions, specication and relative sticker with additional safety information (Fig.37).
1
38
C
10
39
C
12
40
