55
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
is conguration (allowed only with the approved original ue, including the specic non-return valve), makes it possible to suck the
air outside the home or directly from the sha where the ue gas exhaust is present and the evacuation of the ue gas itself inside a collec-
tive ue.
C
10
(Fig. 39):
Coupling to the sha for intake is possible with male ue Ø 80 or Ø 80 cut female.
C
10
- C
12
(Fig. 39 - 40)
e collective ue coupling for the exhaust is possible with female Ø 80 ue with gasket.
Assembly of separator kit Ø 80/80 (Fig. 41):
1. Install the discharge ange (4) on the appliance sample point ange, positioning the relative gasket (1) with the circular projections
downwards in contact with the appliance ange, and tighten using the hex screws with at tip contained in the kit.
2. Remove the at ange present in the intake hole and replace it with the intake ange (3), positioning the gasket (2) contained in the
separator kit Ø 80/80 and tighten using the supplied self-threading screws.
3. Eliminate the extension Ø 125 from the non-return valve kit on the ue gas.
4. Insert the spacer Ø 80 th. 5 mm into the ue exhaust ange.
5.
Victrix Tera V2 28 EU and Victrix Tera V2 32 EU
Maintain the counterweight supplied as per standard (h. 3,5 mm) mounted on the large ap of the valve and discard the one supplied
bulk (h. 6,5 mm) inside the kit (Fig. 34).
Victrix Tera V2 38 EU
Replace the counterweight supplied as per standard (h. 3,5 mm) mounted on the large ap of the valve with the counterweight sup-
plied bulk (h. 6,5 mm) inside the kit. Discard the counterweight (h. 3,5 mm).
6. Insert the ue gas non-return valve on the Ø 80 ues inside the ue exhaust ange.
Make sure to ll the ue gas non-return valve siphon with water (Fig. 34):
7. Fit the bends with male side (smooth) (5) in the female side of the anges (3 and 4).
8. For intake from sha (C
(10)
) i.e. from common intake duct, connect the intake ducts Ø 80 (6) to the bend (5), making sure that the in-
ternal wall sealing plate (7) has already been inserted. For wall intake (C
(12)
), t the intake terminal (6) with the male side (smooth) in
the female side of the bend (5) up to the end stop, ensuring that the internal (7) and external (8) wall sealing plates are tted.
9. Connect the Ø 80 drain pipe making sure to have already inserted the internal wall sealing plate (7) inside the end section of the pipe.
To calculate the length of the ue, simply add, for each component you intend to use, the corresponding value indicated in the
column "Length equivalent to m of pipe" in the table in par. 1.14, and check that the resulting sum is equal to or less than the
maximum length indicated in par. 1.15.
10. Set parameter P8 = 1.
11. Set the fan speed according to the table (par. 3.8).
12. Calibrate the CO
2
at maximum and minimum output (Ref. Par. 4.2).
