Immergas VICTRIX TERA V2 35 PLUS EU - Page 59

59
INSTALLER
USERMAINTENANCE TECHNICIAN
TECHNICAL DATA
Summary table of information for C
10
installations (Only Methane 2E - 2H)
VICTRIX TERA V2 24 PLUS EU
Qmin Qn max
Heat input kW 4,5 28,7
CO2% of reference % 8,5 9,2
Maximum boiler outlet pressure Pa 25 93
Minimum boiler outlet pressure C
10
Pa -200 -200
Minimum boiler outlet pressure C
12
Pa -400 -400
Maximum ue gas ow rate kg\h 46
Minimum ue gas ow rate kg\h 8
Flue gas temperature 80°C\60°C °C 73
Maximum ue duct length 80\125 m 10
Maximum ue duct length 80\80 m 15
Available head with maximum duct length Pa 40,5
Boiler settings
(as indicated in the instruction booklet)
- See Par. 1.24 from point 9 on.
VICTRIX TERA V2 35 PLUS EU
Qmin Qn max
Heat input kW 6,3 38,3
CO2% of reference % 8,5 9,0
Maximum boiler outlet pressure Pa 25 93
Minimum boiler outlet pressure C
10
Pa -200 -200
Minimum boiler outlet pressure C
12
Pa -400 -400
Maximum ue gas ow rate kg\h 63
Minimum ue gas ow rate kg\h 11
Flue gas temperature 80°C\60°C °C 77
Maximum ue duct length 80\125 m 10
Maximum ue duct length 80\80 m 15
Available head with maximum duct length Pa 74,9
Boiler settings
(as indicated in the instruction booklet)
- See Par. 1.24 from point 9 on.
