Inficon XTC/3 User Manual

5 - 35
XTC/3 Operating Manual
12 (0x0c) Zero thickness Zeroes the thickness of the current layer.
13
(0x0d)
Final thickness trigger Causes the active film to react as if the final
thickness was reached.
14
(0x0e)
Crystal switch If a multi-crystal sensor is attached to the
unit, it will switch to the next position.
15
(0x0f)
Enter comm. I/O mode
XTC/3S only.
This indicates that all digital outputs are
under remote communications control,
and their normal functions are overridden.
XTC/3 must be in this mode to remotely set
or clear relays (R17 and R18). If the unit is an
XTC/3M an Illegal ID error is returned.
16
(0x10)
Exit comm. I/O mode
Used in XTC/3S only.
Exits the Communication I/O mode, returns
all digital outputs to normal, XTC/3 controlled
operation. If the unit is an XTC/3M an Illegal
ID error is returned.
17
(0x11)
Set (close) digital output
<Value> vv
vv = <Byte> (output # 1- 20).
In XTC/3S the Communication I/O mode
must be active for this command to operate.
In XTC/3M, the selected output must be set
to Computer Control for this command to
operate.
18
(0x12)
Clear (open) digital output
<Value> vv
vv = <Byte> (output # 1-20).
In XTC/3S the Communication I/O mode
must be active for this command to operate.
In XTC/3M, the selected output must be set
to Computer Control for this command to
operate.
19 (0x13) Turn Backlight on Turns the LCD backlight full on
20 (0x14) Turn Backlight off Turns the LCD backlight full off
21 (0x15) Trigger beeper Sounds an audible beep
22 (0x16) Clear power up error flag Clears the power up error.
26
(0x1a)
Clear All Crystals Sets the crystal status for all the crystals
in the current sensor to good.
Table 5-5 Standard remote commands (continued)
R
(0x52)
Command ID
Function Description
