5.2.2.4.5 Standard Update Input Definition (XTC/3M only)
Command:
UI <Input Number> <Input Definition>|<Input Number = 255> <Input 1 Definition>
<Input 2 Definition> … <Input 9 Definition>
Input Number = <Byte> 1-9 (255=All Inputs)
Input Definition= <Byte> refer to section 5.2.2.3.5 on page 5-14
Response:
None (Just header and trailer)
5.2.2.4.6 Standard Update Output Definition (XTC/3M only)
Command:
UO <Output Number> <Output Definition>
Output Number = <Byte> 1-20 (255=All Outputs)
Output Definition = < Byte > refer to section 5.2.2.3.6 on page 5-15
Response:
None (Just header and trailer)
5.2.2.4.7 Standard Update Output Type Definition (XTC/3M Only)
Command:
UT <Output Number> < Output Type>|< Output Number = 255> < Output 1
Type > < Output 2 Type > … < Output 20 Type >
Output Number = <Byte> 1-20 (255=All Outputs)
Output Type = <Byte> (0 = Normally open, 1 = Normally closed)
Response:
None (Just header and trailer)
16 (0x10)
Auto Start Next Layer
(XTC/3M only)
1 = Yes, 0 = No
Int 0 1
Input Option
(XTC/3S only)
0 = Standard
1 = Film Select
255
(0xff)
1
All Parameters
(Must be in Ready)
1
Cannot change when a film is running.
Table 5-3 Standard general parameters (continued)
UG
(0x5547)
Command ID
Name Units / Allowed
Values / Notes
Data
Type /
Format
Low
Limit
High
Limit
